Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 1,350 kg (O2 Category EU Type-Approved)
-
Payload Capacity: ~1,000 kg – 1,050 kg (Ideal for heavy off-road bodies, roof tents, water tanks, and battery banks)
-
Tare Weight: ~300 kg – 350 kg (Depending on frame dimensions and reinforcement options)
-
Running Gear & Axle: 1x 1,350 kg / 1,500 kg heavy-duty AL-KO or Knott rubber-torsion axle (or optional independent trailing arm suspension for extreme off-road articulation).
-
Coupling & Overrun Braking: Mechanical overrun brake coupling with auto-reverse mechanism and handbrake assembly by AL-KO or Knott.
-
Off-Road Wheels & Tires: Reinforced multi-fit hubs compatible with all-terrain (A/T) or mud-terrain (M/T) off-road tire assemblies.
-
Support & Leveling System: Heavy-duty automatic fold-up jockey wheel (destek tekeri) and 2x rear drop-down corner stabilizer jacks (destek ayağı) for zero-sway camping stability.
-
Chassis Finish: High-tensile structural steel frame, fully protected against stones, mud, and water via full hot-dip galvanization
