Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 1,350 kg (Optimized for robust off-road teardrop and compact hybrid caravans)
-
Payload Capacity: ~900 kg – 1,000 kg (Ample capacity for water tanks, batteries, solar setups, and camping gear)
-
Tare Weight: ~350 kg – 450 kg
-
Axle Configuration: Single Axle system equipped with heavy-duty independent trailing arm suspension or reinforced rubber-torsion off-road axle (AL-KO / Knott components).
-
Chassis & Frame: Laser-cut, high-tensile structural steel chassis, fully hot-dip galvanized and finished with heavy-duty stone-chip protective coating against rust and flying debris.
-
Ground Clearance: Extended high-clearance design with reinforced underbody protection for navigating rocky trails and deep ruts.
-
Coupling & Hitch: Articulating off-road hitch (360-degree rotational coupling) for extreme articulation on uneven terrain, paired with an adjustable heavy-duty V-drawbar.
-
Braking System: Mechanical inertia overrun braking system with auto-reverse and waterproof marine-grade brake drums.
-
Support & Maneuvering: Heavy-duty swing-away jockey wheel and reinforced drop-down stabilizer legs at the rear.
