Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 3,500 kg (Maximum permissible laden mass)
-
Payload Capacity: ~2,300 kg – 2,600 kg (Engineered for high-mass generators, mobile living modules, or machinery)
-
Tare Weight: ~900 kg – 1,200 kg (Depending on sliding superstructure frame and winch configuration)
-
Axle System: Dual / Tandem axle setup (2x 1,800 kg rated heavy-duty torsion axles with marine-sealed hub bearings)
-
Braking & Running Gear: AL-KO or Knott mechanical inertia overrun braking system with auto-reverse function and heavy-duty handbrake assembly.
-
Chassis Construction: Heavy-gauge structural steel raft chassis, fully hot-dip galvanized for maximum structural rigidity and long-term corrosion resistance.
-
Sliding Body Mechanism: Heavy-duty guide rails with roller bearings and manual/hydraulic winch system for effortless loading and unloading of modular containers, mobile home units, or generator skids.
-
Generator & Assembly Integration: Integrated structural mounting points, vibration-damping mounts, sound isolation sub-frame preparation, and reinforced floor crossmembers for continuous heavy machinery operation.
-
Support & Leveling: Heavy-duty automatic fold-up jockey wheel and 4x corner drop-down heavy-duty leveling jacks for stationary stabilization.
