Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 3,500 kg (Maximum permissible laden mass)
-
Payload Capacity: ~2,400 kg – 2,700 kg (Depending on structural framing and tarp height)
-
Tare Weight: ~800 kg – 1,100 kg
-
Axle Configuration: Dual / Tandem Axle system (2x 1,800 kg rated high-durability torsion or leaf-spring axles with integrated brake drums)
-
Running Gear & Braking: Inertia overrun braking system with auto-reverse function (AL-KO or Knott mechanical brake actuators)
-
Chassis & Structure: Fully welded structural steel frame, hot-dip galvanized for superior long-term corrosion resistance.
-
Tarpaulin Superstructure: High-frequency welded, UV-resistant, heavy-duty PVC tarpaulin (approx. 630-900 g/m²) supported by a modular aluminum/steel framework with removable side/rear pillars.
-
Floor & Security: Anti-slip, waterproof marine-grade phenol-coated plywood floor equipped with recessed, heavy-duty internal lashing rings.
-
Access & Loading: Rear drop-down ramp door or double barn doors combined with sliding/removable side curtains for effortless forklift and side-loading operations.
