Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 3,500 kg (EU O2 Category Type-Approved)
-
Payload Capacity: ~2,600 kg – 2,800 kg (Optimized for heavy commercial freight)
-
Tare Weight: ~700 kg – 900 kg (Depending on frame dimensions and superstructure height)
-
Running Gear & Axles: 2x 1,800 kg capacity AL-KO or Knott rubber-torsion tandem axles with integrated mechanical overrun brakes.
-
Coupling & Braking System: Mechanical overrun brake coupling with integrated auto-reverse mechanism and handbrake assembly by AL-KO or Knott.
-
Chassis Construction & Finish: High-tensile S275 / S355 structural steel frame, protected against rust and extreme weather via full hot-dip galvanization (Sıcak Daldırma Galvaniz).
-
Superstructure & Tarpaulin (Branda): Heavy-duty 680 g/m² – 900 g/m² UV-resistant PVC tarpaulin curtain with quick-release side straps, heavy-duty rear double doors (or drop-down tailgate), and removable steel/aluminum corner posts.
-
Flooring: 15 mm – 18 mm water-resistant, anti-slip phenolic resin plywood (Playwood) flooring with flush-mounted tie-down D-rings.
-
Tires & Wheels: High load-index 195/50 R13C or 185 R14C commercial heavy-duty tires mounted on 5-bolt steel rims.
-
Support & Accessories: Automatic fold-up heavy-duty jockey wheel, front/rear stabilizer legs, and thermoplastic mudguards.
