Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 3,500 kg (EU O2 Category Type-Approved)
-
Payload Capacity: ~2,600 kg – 2,750 kg (Designed for heavy mini construction machinery and industrial equipment)
-
Tare Weight: ~750 kg – 900 kg (Varies based on loading ramp and side rail specifications)
-
Running Gear & Axles: 2x 1,800 kg capacity AL-KO or Knott rubber-torsion tandem axles with mechanical overrun brakes.
-
Coupling & V-Drawbar: High-strength V-drawbar (V-Tipi Çeki Oku) fitted with an AL-KO or Knott 3,500 kg overrun braking coupling, integrated auto-reverse mechanism, and emergency breakaway cable.
-
Floor Structure (Sandviç Panel + 18 mm Plywood): Multi-layer high-durability floor construction featuring a thermal/vibration-damping insulated sandwich panel base overlaid with an 18 mm heavy-duty water-resistant phenolic resin plywood (Playwood) top layer with anti-slip pattern and embedded heavy-duty cargo lashing D-rings.
-
Chassis Construction: Heavy-duty S275 / S355 structural steel frame, fully protected against rust and impact via full hot-dip galvanization (Sıcak Daldırma Galvaniz).
-
Ramps & Loading: Rear heavy-duty fold-down loading ramps (or full-width drive-on tailgate) with integrated drop-down rear support legs for safe machinery loading.
-
Tires & Wheels: High load-index 195/50 R13C or 185 R14C commercial heavy-duty tires on 5-bolt steel rims.
