1. Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 3,500 kg (EU O2 Category Type-Approved)
-
Payload Capacity: ~2,700 kg – 2,900 kg (Optimized for heavy timber/steel-framed tiny house structures)
-
Tare Weight: ~600 kg – 800 kg (Depending on frame length and width dimensions)
-
Running Gear & Axles: 2x 1,800 kg capacity AL-KO or Knott mechanical overrun braked rubber-torsion tandem axles.
-
Coupling & Braking System: Mechanical overrun braking system with integrated auto-reverse mechanism and handbrake assembly by AL-KO or Knott.
-
Tires & Wheels: High load-index 195R13C commercial heavy-duty tires mounted on reinforced 5-bolt steel rims (low profile allows lower ride height and increased interior clearance).
-
Support & Leveling System: 4x heavy-duty drop-down corner stabilizer jacks integrated into the main chassis frame, plus an automatic fold-up jockey wheel at the front.
-
Chassis Construction: High-tensile S275 / S355 structural steel construction, fully protected against weather and corrosion via full hot-dip galvanization.
