6000 kg 2-Axle Turntable Military Generator Trailer (Air-Braked & Heavy-Duty)

NEW

6000 kg 2-Axle Turntable Military Generator Trailer (Air-Braked & Heavy-Duty)

Engineered for tactical field deployment, the 6000 kg 2-Axle Turntable Military Generator Trailer features a 360-degree slewing ring, dual-line pneumatic air brakes, 4-corner drop-down leveling legs, and a 2-coat epoxy matte acrylic coating. Compliant with STANAG 4101 and MIL-STD-810H norms to guarantee reliable power delivery in rugged environments. The 6000 kg 2-Axle Turntable Military Generator Trailer is an ultra-rugged tactical logistics platform designed to transport high-capacity power generation units, mobile radar shelters, and field command modules across demanding tactical environments. Featuring a 360-degree turntable steering assembly, dual-line pneumatic air braking, heavy-duty drop-down stabilizer legs, and military-spec surface treatments, this trailer delivers uncompromised mobility and structural integrity under severe off-road and operational conditions.

Description
Order Form

1. Applicable Defense & Military Standards

STANAG 4101: Towing attachment interface and revolving drawbar eye standards for NATO tactical vehicles.
STANAG 4007 / ISO 12098: Standardized 12-pin 24V NATO electrical connector interface for blackout and tactical lighting.
STANAG 4381: Tactical lighting and blackout mode integration for military vehicle operations.
MIL-STD-810H: Environmental engineering considerations and laboratory tests for extreme climate, humidity, vibration, and shock resistance.
MIL-STD-209: Heavy-duty tie-down, lashing, and helicopter/crane lifting shackle points.
MIL-STD-1366: Transportability criteria for military land transport equipment.
MIL-STD-461: Electromagnetic compatibility (EMC) compliance for tactical generator and electronic shelter carriers.
ECE R13: European safety standard for dual-line pneumatic air-braking and EBS/ABS safety integration.

2. Technical Specifications & Features

Gross Vehicle Weight (GVW): 6,000 kg
Payload Capacity: ~4,200 kg – 4,500 kg (Optimized for 150 kVA – 300 kVA+ tactical mobile generators)
Tare Weight: ~1,500 kg – 1,800 kg
Steering & Turntable: Heavy-duty 360-degree ball-bearing slewing ring turntable assembly with a rigid tactical drawbar featuring a STANAG 4101 revolving eye.
Running Gear & Axles: 2x heavy-duty central/turntable axles with integrated vibration-isolation mounts designed for sensitive power electronics.
Braking System: Dual-line pneumatic air braking system with EBS/ABS control, automatic slack adjusters, emergency breakaway valve, and mechanical spring parking brake.
Support & Leveling: 4x heavy-duty drop-down corner leveling jacks (destek ayakları) with wide footplates for zero-sway stability on soft terrain, plus a heavy-duty jockey wheel.
Chassis Construction: High-tensile S355 / S700 MC structural steel frame engineered with integrated cross-members for generator anti-vibration rubber damper mounts.
Coating & Paint Finish: High-durability military coating system featuring 2 coats of anti-corrosive epoxy primer followed by a matte acrylic polyurethane topcoat (optional IR / CARC anti-reflective coating).
