1. Applicable Standards & Quality Norms
-
ECE R13: European safety standard for air-braking and EBS/ABS systems on heavy commercial trailers.
-
ISO 1161: Standardized specifications for ISO container corner twist-lock integrations.
-
AL-KO Quality Standards: Certified running gear components engineered for heavy-duty axle and drawbar assemblies.
-
70/156/EEC / 2007/46/EC: European Union O3 category vehicle type-approval compliant chassis architecture.
2. Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 6,000 kg
-
Payload Capacity: ~4,300 kg – 4,600 kg
-
Tare Weight: ~1,400 kg – 1,700 kg
-
Running Gear & Torsion Axles: 2x AL-KO rubber-torsion central axles equipped with integrated air brakes. Independent wheel suspension ensures vibration-free towing under heavy loads.
-
Braking System: Dual-line pneumatic air braking system with EBS/ABS control unit, automatic slack adjusters, and mechanical parking brake.
-
Drawbar & Coupling: AL-KO height-adjustable drawbar with precision gear-locking mechanism, allowing effortless height adaptation to diverse towing vehicle hitches.
-
Container Lock Mechanism: 4x heavy-duty retractable ISO Twist-Locks integrated directly into the structural frame.
-
Chassis & Finish: High-tensile S355 structural steel frame, fully hot-dip galvanized for extreme corrosion resistance.
-
Support & Maneuvering: Heavy-duty automatic fold-up jockey wheel and rear drop-down corner stabilizer jacks.
