. Applicable International & Military Standards
-
STANAG 4101: Towing attachment standards for 360° rotatable 76,2 mm drawbar eyes and drawbar geometry.
-
STANAG 4007 / MIL-STD-1179: 12-pin 24V NATO electrical interface and blackout lighting system compliance.
-
MIL-STD-810H: Environmental engineering and laboratory testing for shock, vibration, high/low operational temperatures, humidity, sand/dust, and salt fog corrosion resistance.
-
MIL-DTL-53039: Chemical Agent Resistant Coating (CARC) polyurethane matte paint for infrared signature management (RAL 6031 IR CARC Green).
-
ECE R13: European braking regulations for heavy commercial and military trailers (Air-braked category).
-
ISO 1161: Standardized corner casting and mounting dimensions for generator housing payloads.
2. Generator Integration & Technical Specifications
-
Gross Vehicle Weight (GVW): 6,500 kg
-
Payload Capacity: ~4,300 kg – 4,600 kg (Optimized for heavy-duty generator sets and integrated fuel tanks)
-
Tare Weight: ~1,900 kg – 2,200 kg
-
Vibration Damping & Mounting: Integrated heavy-duty Anti-Vibration Mounts (AVM) on the sub-frame to absorb operational engine resonance and isolate dynamic loads during transport.
-
Fuel Tank Provisions: Under-chassis or deck-integrated protected diesel fuel tank cell (300 L – 600 L capacity) with direct generator feed and drainage lines.
-
Axle & Suspension System: Dual central (Tandem) axle configuration equipped with heavy-duty multi-leaf spring or air suspension, fitted with sealed, waterproof wheel hubs.
-
Braking System: Dual-line pneumatic air braking system with ABS/EBS (Wabco / Knorr-Bremse compatible), mechanical handbrake, and emergency breakaway safety valves.
-
Drawbar & Coupling: STANAG 4101 compliant 360-degree rotatable 50 mm drawbar eye with a mechanically/hydraulically height-adjustable drawbar assembly.
-
Leveling & Field Stabilization: Equipped with 4x corner drop-down heavy-duty leveling jacks and a heavy-duty fold-up jockey wheel for stationary leveling on uneven field terrain.
