. Applicable Defense & Military Standards
-
STANAG 4101: Towing attachment interface, revolving drawbar eye, and coupling standards for tactical military vehicles.
-
STANAG 4007 / ISO 12098: Standardized 12-pin 24V NATO electrical connector interface for tactical and blackout lighting systems.
-
STANAG 4381: Tactical blackout lighting system integration for covert field operations.
-
MIL-STD-810H: Environmental testing compliance for extreme desert/arctic temperatures, sand/dust, vibration, and shock resistance.
-
MIL-STD-209: Certified heavy-duty tie-down, lashing, and crane/helicopter lifting points.
-
ECE R13: European safety standard for dual-line pneumatic air braking with EBS/ABS and Roll Stability Support (RSS).
-
Food Grade / Sanitation Standards: AISI 316L / 304 stainless steel interior lining compliance for safe drinking water storage in military field camps.
2. Technical Specifications & Features
-
Gross Vehicle Weight (GVW): 7,000 kg
-
Tank Liquid Capacity: 4,000 Liters – 5,000 Liters (Potable water, utility water, or liquid distribution).
-
Tare Weight: ~2,000 kg – 2,400 kg (Varies based on tank material and pump system options).
-
Steering & Axle Configuration: Dual-axle turntable design (Döner tablalı / Dönerli ön aks). The front axle rotates 360 degrees on a heavy-duty ball-bearing turntable ring, transferring zero vertical hitch load to the towing truck.
-
Axles & Suspension: 2x 4,500 kg capacity heavy-duty tactical axles fitted with parabolic leaf springs and heavy-duty shock absorbers.
-
Tank Construction & Insulation: AISI 304 or AISI 316L food-grade stainless steel (or heavy-duty GRP/steel with inner epoxy coating) featuring internal surge baffles (dalgakıran) to minimize fluid sloshing during dynamic off-road maneuvers.
-
Pumping & Distribution System: Onboard 24V electro-hydraulic or diesel-engine driven high-flow water pump, integrated stainless steel hose reels, rear gravity-feed dispensing valves, and lockable protective control cabinets.
-
Braking System: Dual-line pneumatic air braking system with WABCO/Knorr EBS 2S/2M, automatic slack adjusters, and spring parking brake chambers.
-
Wheels & Tires: Off-road heavy-duty All-Terrain / Mud-Terrain tires (e.g., 12.5 R20 or 385/65 R22.5 tactical equivalents) mounted on 10-hole steel rims.
-
Coating & Paint Finish: Shot-blasted structural frame coated with 2 coats of anti-corrosive epoxy primer and a Chemical Agent Resistant Coating (CARC) / matte military acrylic topcoat in NATO green, desert tan, or black.
